JCB MICRO Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: JCB MICRO Crawler Excavator in jobsite field operations

JCB logoMini Excavator

JCB MICRO

Micro Excavator (< 2t) · Crawler Chassis

Operating Weight1.1 T Class
1,138 kg
≈ 2,508.9 lbs
Max Dig DepthGround Reach
1.73 m
≈ 5.7 ft
Net Engine PowerCrawler
17 HP
≈ 13 kW
Verified Technical Fact Sheet · JCB MICRO

The official operating weight of the JCB MICRO is 1,138 kg (2,508.9 lbs), with a net engine output of 17 HP and a maximum digging depth of 1.73 m. Classified as a Micro Excavator (< 2t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
103-10 MICRO
Net Power
17 HP (13 kW)
Gross Power
18.2 HP
Displacement
0.95 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
1,138 kg
Weight (lbs)
2,508.9 lbs
Hydraulic System Flow
13.6 L/min
Fuel Tank Capacity
N/A
Standard Bucket
N/A

Working Dimensions & Dig Depth

Max Digging Depth
1.73 m (5.7 ft)
Max Reach (Ground)
3.18 m
Max Dump Height
1.91 m
Shipping Width
686 mm
Shipping Height
2286 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
JCB Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world JCB MICRO jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about JCB MICRO

How much does a JCB MICRO excavator weigh?

The official operating weight of the JCB MICRO hydraulic excavator is 1,138 kg (2,508.9 lbs) (1.1 metric tonnes), categorizing it within the Micro Excavator (< 2t) range.

What is the maximum digging depth of the JCB MICRO?

The maximum digging depth for the JCB MICRO is 1.73 m (5.7 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the JCB MICRO have?

The JCB MICRO is powered by a 103-10 MICRO powertrain delivering 17 HP (13 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the JCB MICRO?

The JCB MICRO is classified as a Micro Excavator (< 2t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
