Jonyang JY640 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Jonyang JY640 Crawler Excavator in jobsite field operations

Jonyang logoHydraulic Excavator

Jonyang JY640

Large Excavator (25 - 50t) · Crawler Chassis

Operating Weight36.3 T Class
36,288 kg
≈ 80,001.3 lbs
Max Dig DepthGround Reach
7.75 m
≈ 25.4 ft
Net Engine PowerCrawler
315.2 HP
≈ 235 kW
Verified Technical Fact Sheet · Jonyang JY640

The official operating weight of the Jonyang JY640 is 36,288 kg (80,001.3 lbs), with a net engine output of 315.2 HP and a maximum digging depth of 7.75 m. Classified as a Large Excavator (25 - 50t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
M11-C315
Net Power
315.2 HP (235 kW)
Gross Power
315.2 HP
Displacement
N/A
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
36,288 kg
Weight (lbs)
80,001.3 lbs
Hydraulic System Flow
720.4 L/min
Fuel Tank Capacity
N/A
Standard Bucket
N/A

Working Dimensions & Dig Depth

Max Digging Depth
7.75 m (25.4 ft)
Max Reach (Ground)
12.09 m
Max Dump Height
8.73 m
Shipping Width
3353 mm
Shipping Height
3612 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Jonyang Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Jonyang JY640 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Jonyang JY640

How much does a Jonyang JY640 excavator weigh?

The official operating weight of the Jonyang JY640 hydraulic excavator is 36,288 kg (80,001.3 lbs) (36.3 metric tonnes), categorizing it within the Large Excavator (25 - 50t) range.

What is the maximum digging depth of the Jonyang JY640?

The maximum digging depth for the Jonyang JY640 is 7.75 m (25.4 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Jonyang JY640 have?

The Jonyang JY640 is powered by a M11-C315 powertrain delivering 315.2 HP (235 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Jonyang JY640?

The Jonyang JY640 is classified as a Large Excavator (25 - 50t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
