Kato HD1430III Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Kato HD1430III Crawler Excavator in jobsite field operations

Kato logoHydraulic Excavator

Kato HD1430III

Large Excavator (25 - 50t) · Crawler Chassis

Operating Weight30.2 T Class
30,200 kg
≈ 66,579.5 lbs
Max Dig DepthGround Reach
7.48 m
≈ 24.6 ft
Net Engine PowerCrawler
N/A
≈ N/A
Verified Technical Fact Sheet · Kato HD1430III

The official operating weight of the Kato HD1430III is 30,200 kg (66,579.5 lbs), with a net engine output of N/A and a maximum digging depth of 7.48 m. Classified as a Large Excavator (25 - 50t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
C 6D16-TLE2A
Net Power
N/A
Gross Power
245.5 HP
Displacement
7.54 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
30,200 kg
Weight (lbs)
66,579.5 lbs
Hydraulic System Flow
602.3 L/min
Fuel Tank Capacity
N/A
Standard Bucket
1.45 m³

Working Dimensions & Dig Depth

Max Digging Depth
7.48 m (24.6 ft)
Max Reach (Ground)
N/A
Max Dump Height
7.57 m
Shipping Width
3200 mm
Shipping Height
3021 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Kato Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Kato HD1430III jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Kato HD1430III

How much does a Kato HD1430III excavator weigh?

The official operating weight of the Kato HD1430III hydraulic excavator is 30,200 kg (66,579.5 lbs) (30.2 metric tonnes), categorizing it within the Large Excavator (25 - 50t) range.

What is the maximum digging depth of the Kato HD1430III?

The maximum digging depth for the Kato HD1430III is 7.48 m (24.6 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Kato HD1430III have?

The Kato HD1430III is powered by a C 6D16-TLE2A powertrain delivering N/A net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Kato HD1430III?

The Kato HD1430III is classified as a Large Excavator (25 - 50t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
