Kato HD1880VII Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: None

Caption: Kato HD1880VII Crawler Excavator in jobsite field operations

Kato logoHydraulic Excavator

Kato HD1880VII

Large Excavator (25 - 50t) · Crawler Chassis

Operating Weight43.5 T Class
43,500 kg
≈ 95,901 lbs
Max Dig DepthGround Reach
7.27 m
≈ 23.9 ft
Net Engine PowerCrawler
286 HP
≈ 213 kW
Verified Technical Fact Sheet · Kato HD1880VII

The official operating weight of the Kato HD1880VII is 43,500 kg (95,901 lbs), with a net engine output of 286 HP and a maximum digging depth of 7.27 m. Classified as a Large Excavator (25 - 50t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
6D22-TC
Net Power
286 HP (213 kW)
Gross Power
285.7 HP
Displacement
11.15 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
43,500 kg
Weight (lbs)
95,901 lbs
Hydraulic System Flow
720.4 L/min
Fuel Tank Capacity
N/A
Standard Bucket
2.06 m³

Working Dimensions & Dig Depth

Max Digging Depth
7.27 m (23.9 ft)
Max Reach (Ground)
13.37 m
Max Dump Height
8.96 m
Shipping Width
3103 mm
Shipping Height
3472 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Kato Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Kato HD1880VII jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Kato HD1880VII

How much does a Kato HD1880VII excavator weigh?

The official operating weight of the Kato HD1880VII hydraulic excavator is 43,500 kg (95,901 lbs) (43.5 metric tonnes), categorizing it within the Large Excavator (25 - 50t) range.

What is the maximum digging depth of the Kato HD1880VII?

The maximum digging depth for the Kato HD1880VII is 7.27 m (23.9 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Kato HD1880VII have?

The Kato HD1880VII is powered by a 6D22-TC powertrain delivering 286 HP (213 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Kato HD1880VII?

The Kato HD1880VII is classified as a Large Excavator (25 - 50t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
