Kato HD820IIILC Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Kato HD820IIILC Crawler Excavator in jobsite field operations

Kato logoHydraulic Excavator

Kato HD820IIILC

Medium Excavator (10 - 25t) · Crawler Chassis

Operating Weight20.3 T Class
20,300 kg
≈ 44,753.8 lbs
Max Dig DepthGround Reach
6.12 m
≈ 20.1 ft
Net Engine PowerCrawler
N/A
≈ N/A
Verified Technical Fact Sheet · Kato HD820IIILC

The official operating weight of the Kato HD820IIILC is 20,300 kg (44,753.8 lbs), with a net engine output of N/A and a maximum digging depth of 6.12 m. Classified as a Medium Excavator (10 - 25t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
C 6D34-TLE2A
Net Power
N/A
Gross Power
147.6 HP
Displacement
5.86 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
20,300 kg
Weight (lbs)
44,753.8 lbs
Hydraulic System Flow
470.1 L/min
Fuel Tank Capacity
N/A
Standard Bucket
0.84 m³

Working Dimensions & Dig Depth

Max Digging Depth
6.12 m (20.1 ft)
Max Reach (Ground)
10.66 m
Max Dump Height
7.26 m
Shipping Width
2990 mm
Shipping Height
2801 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Kato Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Kato HD820IIILC jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Kato HD820IIILC

How much does a Kato HD820IIILC excavator weigh?

The official operating weight of the Kato HD820IIILC hydraulic excavator is 20,300 kg (44,753.8 lbs) (20.3 metric tonnes), categorizing it within the Medium Excavator (10 - 25t) range.

What is the maximum digging depth of the Kato HD820IIILC?

The maximum digging depth for the Kato HD820IIILC is 6.12 m (20.1 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Kato HD820IIILC have?

The Kato HD820IIILC is powered by a C 6D34-TLE2A powertrain delivering N/A net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Kato HD820IIILC?

The Kato HD820IIILC is classified as a Medium Excavator (10 - 25t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
