Kobelco 13SR Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Tuff Diesel

Caption: Authentic in-field operation footage capture of Kobelco 13SR

Kobelco logoMini Excavator

Kobelco 13SR

Partially Source-Verified

Micro Excavator (< 2t) · Crawler Chassis

Operating Weight1.3 T Class
1,340 kg
≈ 2,954.2 lbs
Max Dig DepthGround Reach
2.00 m
≈ 6.6 ft
Net Engine PowerCrawler
12 HP
≈ 9 kW
Verified Technical Fact Sheet · Kobelco 13SR

The official operating weight of the Kobelco 13SR is 1,340 kg (2,954.2 lbs), with a net engine output of 12 HP and a maximum digging depth of 2.00 m. Classified as a Micro Excavator (< 2t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
3TNE68-YB
Net Power
12 HP (9 kW)
Gross Power
12 HP
Displacement
0.78 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
1,340 kg
Weight (lbs)
2,954.2 lbs
Hydraulic System Flow
N/A
Fuel Tank Capacity
N/A
Standard Bucket
0.08 m³

Working Dimensions & Dig Depth

Max Digging Depth
2.00 m (6.6 ft)
Max Reach (Ground)
3.68 m
Max Dump Height
2.56 m
Shipping Width
890 mm
Shipping Height
2502 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Kobelco

Kobelco 13SR Specification Sheet

Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Region: NA
Engine Rating Standards
Net: ISO 9249
Gross: ISO 14396
Market: NA
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Kobelco 13SR jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Kobelco 13SR

How much does a Kobelco 13SR excavator weigh?

The official operating weight of the Kobelco 13SR hydraulic excavator is 1,340 kg (2,954.2 lbs) (1.3 metric tonnes), categorizing it within the Micro Excavator (< 2t) range.

What is the maximum digging depth of the Kobelco 13SR?

The maximum digging depth for the Kobelco 13SR is 2.00 m (6.6 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Kobelco 13SR have?

The Kobelco 13SR is powered by a 3TNE68-YB powertrain delivering 12 HP (9 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Kobelco 13SR?

The Kobelco 13SR is classified as a Micro Excavator (< 2t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
