Link-Belt BELT130X2LC Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Link-Belt BELT130X2LC Crawler Excavator in jobsite field operations

Link-Belt logoHydraulic Excavator

Link-Belt BELT130X2LC

Medium Excavator (10 - 25t) · Crawler Chassis

Operating Weight12.9 T Class
12,900 kg
≈ 28,439.6 lbs
Max Dig DepthGround Reach
5.35 m
≈ 17.6 ft
Net Engine PowerCrawler
95 HP
≈ 71 kW
Verified Technical Fact Sheet · Link-Belt BELT130X2LC

The official operating weight of the Link-Belt BELT130X2LC is 12,900 kg (28,439.6 lbs), with a net engine output of 95 HP and a maximum digging depth of 5.35 m. Classified as a Medium Excavator (10 - 25t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
AJ-4JJ1X
Net Power
95 HP (71 kW)
Gross Power
95 HP
Displacement
3 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
12,900 kg
Weight (lbs)
28,439.6 lbs
Hydraulic System Flow
258.2 L/min
Fuel Tank Capacity
N/A
Standard Bucket
0.54 m³

Working Dimensions & Dig Depth

Max Digging Depth
5.35 m (17.6 ft)
Max Reach (Ground)
8.64 m
Max Dump Height
6.68 m
Shipping Width
2591 mm
Shipping Height
2880 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Link-Belt Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Link-Belt BELT130X2LC jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Link-Belt BELT130X2LC

How much does a Link-Belt BELT130X2LC excavator weigh?

The official operating weight of the Link-Belt BELT130X2LC hydraulic excavator is 12,900 kg (28,439.6 lbs) (12.9 metric tonnes), categorizing it within the Medium Excavator (10 - 25t) range.

What is the maximum digging depth of the Link-Belt BELT130X2LC?

The maximum digging depth for the Link-Belt BELT130X2LC is 5.35 m (17.6 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Link-Belt BELT130X2LC have?

The Link-Belt BELT130X2LC is powered by a AJ-4JJ1X powertrain delivering 95 HP (71 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Link-Belt BELT130X2LC?

The Link-Belt BELT130X2LC is classified as a Medium Excavator (10 - 25t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
