Caption: Link-Belt BELT160X2 Crawler Excavator in jobsite field operations
Hydraulic ExcavatorLink-Belt BELT160X2
Medium Excavator (10 - 25t) · Crawler Chassis
Operating Weight17.1 T Class
17,100 kg
≈ 37,699 lbs
Max Dig DepthGround Reach
5.22 m
≈ 17.1 ft
Net Engine PowerCrawler
120 HP
≈ 89 kW
Advertisement
[ Ad Slot: model-mid-banner ]
Authentic In-Field Operation Footage
Real-world Link-Belt BELT160X2 jobsite telemetry & machine handling demonstration
Channel: I35 Equipment
Engine & Powertrain
- Engine Make / Model
- AI-4JJ1X
- Net Power
- 120 HP (89 kW)
- Gross Power
- 120 HP
- Displacement
- 3 L
- Emissions Standard
- EPA Tier 4 / EU Stage V
Operational & Hydraulic Flow
- Operating Weight
- 17,100 kg
- Weight (lbs)
- 37,699 lbs
- Hydraulic Flow
- 283.9 L/min
- Fuel Tank Capacity
- N/A
- Standard Bucket
- 0.76 m³
Working Dimensions & Dig Depth
- Max Digging Depth
- 5.22 m (17.1 ft)
- Max Reach (Ground)
- 9.22 m
- Max Dump Height
- 6.69 m
- Shipping Width
- 2582 mm
- Shipping Height
- 3130 mm
