Caption: Link-Belt BELT225SPINACE Crawler Excavator in jobsite field operations
Link-Belt BELT225SPINACE
Medium Excavator (10 - 25t) · Crawler Chassis
The official operating weight of the Link-Belt BELT225SPINACE is 23,304 kg (51,376.5 lbs), with a net engine output of 138 HP and a maximum digging depth of 6.06 m. Classified as a Medium Excavator (10 - 25t) (Crawler chassis).
Engine & Powertrain
- Engine Make / Model
- BB-6BG1T
- Net Power
- 138 HP (103 kW)
- Gross Power
- 138 HP
- Displacement
- 6.49 L
- Emissions Standard
- EPA Tier 4 / EU Stage V
Operational & Hydraulics
- Operating Weight
- 23,304 kg
- Weight (lbs)
- 51,376.5 lbs
- Hydraulic System Flow
- 380.1 L/min
- Fuel Tank Capacity
- N/A
- Standard Bucket
- 0.84 m³
Working Dimensions & Dig Depth
- Max Digging Depth
- 6.06 m (19.9 ft)
- Max Reach (Ground)
- 9.73 m
- Max Dump Height
- 8.02 m
- Shipping Width
- 3191 mm
- Shipping Height
- 3240 mm
Source & Configuration
Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.
Authentic In-Field Operation Footage
Real-world Link-Belt BELT225SPINACE jobsite telemetry & machine handling demonstration
Frequently Asked Questions about Link-Belt BELT225SPINACE
How much does a Link-Belt BELT225SPINACE excavator weigh?
The official operating weight of the Link-Belt BELT225SPINACE hydraulic excavator is 23,304 kg (51,376.5 lbs) (23.3 metric tonnes), categorizing it within the Medium Excavator (10 - 25t) range.
What is the maximum digging depth of the Link-Belt BELT225SPINACE?
The maximum digging depth for the Link-Belt BELT225SPINACE is 6.06 m (19.9 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.
What engine and horsepower does the Link-Belt BELT225SPINACE have?
The Link-Belt BELT225SPINACE is powered by a BB-6BG1T powertrain delivering 138 HP (103 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.
What class of excavator is the Link-Belt BELT225SPINACE?
The Link-Belt BELT225SPINACE is classified as a Medium Excavator (10 - 25t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
