Link-Belt BELT370LXROADBUILDER Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: LBXCO

Caption: Authentic in-field operation footage capture of Link-Belt BELT370LXROADBUILDER

Link-Belt logoHydraulic Excavator

Link-Belt BELT370LXROADBUILDER

Large Excavator (25 - 50t) · Crawler Chassis

Operating Weight44.4 T Class
44,403 kg
≈ 97,891.7 lbs
Max Dig DepthGround Reach
5.06 m
≈ 16.6 ft
Net Engine PowerCrawler
247 HP
≈ 184 kW
Verified Technical Fact Sheet · Link-Belt BELT370LXROADBUILDER

The official operating weight of the Link-Belt BELT370LXROADBUILDER is 44,403 kg (97,891.7 lbs), with a net engine output of 247 HP and a maximum digging depth of 5.06 m. Classified as a Large Excavator (25 - 50t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
AA-6HK1XQB
Net Power
247 HP (184 kW)
Gross Power
247 HP
Displacement
7.78 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
44,403 kg
Weight (lbs)
97,891.7 lbs
Hydraulic System Flow
567.8 L/min
Fuel Tank Capacity
N/A
Standard Bucket
N/A

Working Dimensions & Dig Depth

Max Digging Depth
5.06 m (16.6 ft)
Max Reach (Ground)
10.92 m
Max Dump Height
8.80 m
Shipping Width
3642 mm
Shipping Height
3478 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Link-Belt Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Link-Belt BELT370LXROADBUILDER jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Link-Belt BELT370LXROADBUILDER

How much does a Link-Belt BELT370LXROADBUILDER excavator weigh?

The official operating weight of the Link-Belt BELT370LXROADBUILDER hydraulic excavator is 44,403 kg (97,891.7 lbs) (44.4 metric tonnes), categorizing it within the Large Excavator (25 - 50t) range.

What is the maximum digging depth of the Link-Belt BELT370LXROADBUILDER?

The maximum digging depth for the Link-Belt BELT370LXROADBUILDER is 5.06 m (16.6 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Link-Belt BELT370LXROADBUILDER have?

The Link-Belt BELT370LXROADBUILDER is powered by a AA-6HK1XQB powertrain delivering 247 HP (184 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Link-Belt BELT370LXROADBUILDER?

The Link-Belt BELT370LXROADBUILDER is classified as a Large Excavator (25 - 50t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
