Link-Belt BELT8000QUANTUM Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Link-Belt BELT8000QUANTUM Crawler Excavator in jobsite field operations

Link-Belt logoHydraulic Excavator

Link-Belt BELT8000QUANTUM

Mining Excavator (> 50t) · Crawler Chassis

Operating Weight80.0 T Class
80,015 kg
≈ 176,402.7 lbs
Max Dig DepthGround Reach
6.44 m
≈ 21.1 ft
Net Engine PowerCrawler
438 HP
≈ 327 kW
Verified Technical Fact Sheet · Link-Belt BELT8000QUANTUM

The official operating weight of the Link-Belt BELT8000QUANTUM is 80,015 kg (176,402.7 lbs), with a net engine output of 438 HP and a maximum digging depth of 6.44 m. Classified as a Mining Excavator (> 50t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
N14-C460-1.5c
Net Power
438 HP (327 kW)
Gross Power
438 HP
Displacement
14.01 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
80,015 kg
Weight (lbs)
176,402.7 lbs
Hydraulic System Flow
1000.1 L/min
Fuel Tank Capacity
N/A
Standard Bucket
3.06 m³

Working Dimensions & Dig Depth

Max Digging Depth
6.44 m (21.1 ft)
Max Reach (Ground)
15.92 m
Max Dump Height
10.40 m
Shipping Width
4200 mm
Shipping Height
4752 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Link-Belt Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Link-Belt BELT8000QUANTUM jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Link-Belt BELT8000QUANTUM

How much does a Link-Belt BELT8000QUANTUM excavator weigh?

The official operating weight of the Link-Belt BELT8000QUANTUM hydraulic excavator is 80,015 kg (176,402.7 lbs) (80 metric tonnes), categorizing it within the Mining Excavator (> 50t) range.

What is the maximum digging depth of the Link-Belt BELT8000QUANTUM?

The maximum digging depth for the Link-Belt BELT8000QUANTUM is 6.44 m (21.1 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Link-Belt BELT8000QUANTUM have?

The Link-Belt BELT8000QUANTUM is powered by a N14-C460-1.5c powertrain delivering 438 HP (327 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Link-Belt BELT8000QUANTUM?

The Link-Belt BELT8000QUANTUM is classified as a Mining Excavator (> 50t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
