Mustang 5003ZT Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Mustang 5003ZT Crawler Excavator in jobsite field operations

Mustang logoMidi Excavator

Mustang 5003ZT

Mini Excavator (2 - 6t) · Crawler Chassis

Operating Weight4.8 T Class
4,775 kg
≈ 10,527.1 lbs
Max Dig DepthGround Reach
2.92 m
≈ 9.6 ft
Net Engine PowerCrawler
38 HP
≈ 28 kW
Verified Technical Fact Sheet · Mustang 5003ZT

The official operating weight of the Mustang 5003ZT is 4,775 kg (10,527.1 lbs), with a net engine output of 38 HP and a maximum digging depth of 2.92 m. Classified as a Mini Excavator (2 - 6t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
4TNV88-PNS
Net Power
38 HP (28 kW)
Gross Power
48 HP
Displacement
2.19 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
4,775 kg
Weight (lbs)
10,527.1 lbs
Hydraulic System Flow
166.2 L/min
Fuel Tank Capacity
N/A
Standard Bucket
0.15 m³

Working Dimensions & Dig Depth

Max Digging Depth
2.92 m (9.6 ft)
Max Reach (Ground)
6.17 m
Max Dump Height
3.89 m
Shipping Width
1981 mm
Shipping Height
2566 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Mustang Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Mustang 5003ZT jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Mustang 5003ZT

How much does a Mustang 5003ZT excavator weigh?

The official operating weight of the Mustang 5003ZT hydraulic excavator is 4,775 kg (10,527.1 lbs) (4.8 metric tonnes), categorizing it within the Mini Excavator (2 - 6t) range.

What is the maximum digging depth of the Mustang 5003ZT?

The maximum digging depth for the Mustang 5003ZT is 2.92 m (9.6 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Mustang 5003ZT have?

The Mustang 5003ZT is powered by a 4TNV88-PNS powertrain delivering 38 HP (28 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Mustang 5003ZT?

The Mustang 5003ZT is classified as a Mini Excavator (2 - 6t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
