Samsung SE280NLC3 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: gomotors.net (carinstance)

Caption: Samsung SE280NLC3 Crawler Excavator in jobsite field operations

Samsung logoHydraulic Excavator

Samsung SE280NLC3

Large Excavator (25 - 50t) · Crawler Chassis

Operating Weight27.8 T Class
27,800 kg
≈ 61,288.4 lbs
Max Dig DepthGround Reach
7.03 m
≈ 23.1 ft
Net Engine PowerCrawler
197 HP
≈ 147 kW
Verified Technical Fact Sheet · Samsung SE280NLC3

The official operating weight of the Samsung SE280NLC3 is 27,800 kg (61,288.4 lbs), with a net engine output of 197 HP and a maximum digging depth of 7.03 m. Classified as a Large Excavator (25 - 50t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
C8.3-C
Net Power
197 HP (147 kW)
Gross Power
215 HP
Displacement
8.27 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
27,800 kg
Weight (lbs)
61,288.4 lbs
Hydraulic System Flow
500.1 L/min
Fuel Tank Capacity
N/A
Standard Bucket
1.3 m³

Working Dimensions & Dig Depth

Max Digging Depth
7.03 m (23.1 ft)
Max Reach (Ground)
11.40 m
Max Dump Height
7.45 m
Shipping Width
2990 mm
Shipping Height
3621 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Samsung Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Samsung SE280NLC3 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Samsung SE280NLC3

How much does a Samsung SE280NLC3 excavator weigh?

The official operating weight of the Samsung SE280NLC3 hydraulic excavator is 27,800 kg (61,288.4 lbs) (27.8 metric tonnes), categorizing it within the Large Excavator (25 - 50t) range.

What is the maximum digging depth of the Samsung SE280NLC3?

The maximum digging depth for the Samsung SE280NLC3 is 7.03 m (23.1 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Samsung SE280NLC3 have?

The Samsung SE280NLC3 is powered by a C8.3-C powertrain delivering 197 HP (147 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Samsung SE280NLC3?

The Samsung SE280NLC3 is classified as a Large Excavator (25 - 50t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
