Caption: Sumitomo SH220 Crawler Excavator in jobsite field operations
Hydraulic ExcavatorSumitomo SH220
Medium Excavator (10 - 25t) · Crawler Chassis
Operating Weight22.8 T Class
22,840 kg
≈ 50,353.5 lbs
Max Dig DepthGround Reach
6.67 m
≈ 21.9 ft
Net Engine PowerCrawler
153 HP
≈ 114 kW
Advertisement
[ Ad Slot: model-mid-banner ]
Authentic In-Field Operation Footage
Real-world Sumitomo SH220 jobsite telemetry & machine handling demonstration
Channel: RDW
Engine & Powertrain
- Engine Make / Model
- 6BG1T
- Net Power
- 153 HP (114 kW)
- Gross Power
- 153 HP
- Displacement
- 6.49 L
- Emissions Standard
- EPA Tier 4 / EU Stage V
Operational & Hydraulic Flow
- Operating Weight
- 22,840 kg
- Weight (lbs)
- 50,353.5 lbs
- Hydraulic Flow
- N/A
- Fuel Tank Capacity
- N/A
- Standard Bucket
- 0.92 m³
Working Dimensions & Dig Depth
- Max Digging Depth
- 6.67 m (21.9 ft)
- Max Reach (Ground)
- 10.83 m
- Max Dump Height
- 6.89 m
- Shipping Width
- 2990 mm
- Shipping Height
- 3051 mm
