Takeuchi TB007 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Takeuchi TB007 Crawler Excavator in jobsite field operations

Takeuchi logoMini Excavator

Takeuchi TB007

Source-Verified

Micro Excavator (< 2t) · Crawler Chassis

Operating Weight0.8 T Class
780 kg
≈ 1,719.6 lbs
Max Dig DepthGround Reach
1.54 m
≈ 5.1 ft
Net Engine PowerCrawler
8.4 HP
≈ 6 kW
Verified Technical Fact Sheet · Takeuchi TB007

The official operating weight of the Takeuchi TB007 is 780 kg (1,719.6 lbs), with a net engine output of 8.4 HP and a maximum digging depth of 1.54 m. Classified as a Micro Excavator (< 2t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
2TN66L
Net Power
8.4 HP (6 kW)
Gross Power
8.4 HP
Displacement
0.44 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
780 kg
Weight (lbs)
1,719.6 lbs
Hydraulic System Flow
16 L/min
Fuel Tank Capacity
N/A
Standard Bucket
N/A

Working Dimensions & Dig Depth

Max Digging Depth
1.54 m (5.1 ft)
Max Reach (Ground)
2.72 m
Max Dump Height
2.01 m
Shipping Width
741 mm
Shipping Height
2033 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Takeuchi

Takeuchi TB007 Official Specification Sheet

Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Region: NA
Engine Rating Standards
Net: ISO 9249
Gross: ISO 14396
Market: NA
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Takeuchi TB007 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Takeuchi TB007

How much does a Takeuchi TB007 excavator weigh?

The official operating weight of the Takeuchi TB007 hydraulic excavator is 780 kg (1,719.6 lbs) (0.8 metric tonnes), categorizing it within the Micro Excavator (< 2t) range.

What is the maximum digging depth of the Takeuchi TB007?

The maximum digging depth for the Takeuchi TB007 is 1.54 m (5.1 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Takeuchi TB007 have?

The Takeuchi TB007 is powered by a 2TN66L powertrain delivering 8.4 HP (6 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Takeuchi TB007?

The Takeuchi TB007 is classified as a Micro Excavator (< 2t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
