Terex 2205M Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Terex 2205M Crawler Excavator in jobsite field operations

Terex logoMobile Excavator

Terex 2205M

Medium Excavator (10 - 25t) · Crawler Chassis

Operating Weight21.1 T Class
21,100 kg
≈ 46,517.5 lbs
Max Dig DepthGround Reach
6.60 m
≈ 21.7 ft
Net Engine PowerCrawler
182 HP
≈ 136 kW
Verified Technical Fact Sheet · Terex 2205M

The official operating weight of the Terex 2205M is 21,100 kg (46,517.5 lbs), with a net engine output of 182 HP and a maximum digging depth of 6.60 m. Classified as a Medium Excavator (10 - 25t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
BF6M 2012 C
Net Power
182 HP (136 kW)
Gross Power
182 HP
Displacement
6 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
21,100 kg
Weight (lbs)
46,517.5 lbs
Hydraulic System Flow
460.3 L/min
Fuel Tank Capacity
N/A
Standard Bucket
1.15 m³

Working Dimensions & Dig Depth

Max Digging Depth
6.60 m (21.7 ft)
Max Reach (Ground)
N/A
Max Dump Height
N/A
Shipping Width
N/A
Shipping Height
3121 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Terex Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Terex 2205M jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Terex 2205M

How much does a Terex 2205M excavator weigh?

The official operating weight of the Terex 2205M hydraulic excavator is 21,100 kg (46,517.5 lbs) (21.1 metric tonnes), categorizing it within the Medium Excavator (10 - 25t) range.

What is the maximum digging depth of the Terex 2205M?

The maximum digging depth for the Terex 2205M is 6.60 m (21.7 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Terex 2205M have?

The Terex 2205M is powered by a BF6M 2012 C powertrain delivering 182 HP (136 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Terex 2205M?

The Terex 2205M is classified as a Medium Excavator (10 - 25t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
