Terex HML42 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Peter M (compubuzz)

Caption: Terex HML42 Crawler Excavator in jobsite field operations

Terex logoMobile Excavator

Terex HML42

Medium Excavator (10 - 25t) · Crawler Chassis

Operating Weight11.0 T Class
10,990 kg
≈ 24,228.8 lbs
Max Dig DepthGround Reach
3.67 m
≈ 12.0 ft
Net Engine PowerCrawler
91 HP
≈ 68 kW
Verified Technical Fact Sheet · Terex HML42

The official operating weight of the Terex HML42 is 10,990 kg (24,228.8 lbs), with a net engine output of 91 HP and a maximum digging depth of 3.67 m. Classified as a Medium Excavator (10 - 25t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
BF4 M 2012
Net Power
91 HP (68 kW)
Gross Power
91 HP
Displacement
4 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
10,990 kg
Weight (lbs)
24,228.8 lbs
Hydraulic System Flow
200.2 L/min
Fuel Tank Capacity
N/A
Standard Bucket
0.15 m³

Working Dimensions & Dig Depth

Max Digging Depth
3.67 m (12 ft)
Max Reach (Ground)
8.30 m
Max Dump Height
6.04 m
Shipping Width
N/A
Shipping Height
3002 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Terex Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Terex HML42 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Terex HML42

How much does a Terex HML42 excavator weigh?

The official operating weight of the Terex HML42 hydraulic excavator is 10,990 kg (24,228.8 lbs) (11 metric tonnes), categorizing it within the Medium Excavator (10 - 25t) range.

What is the maximum digging depth of the Terex HML42?

The maximum digging depth for the Terex HML42 is 3.67 m (12.0 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Terex HML42 have?

The Terex HML42 is powered by a BF4 M 2012 powertrain delivering 91 HP (68 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Terex HML42?

The Terex HML42 is classified as a Medium Excavator (10 - 25t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
