Terex HR32 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Pinterest Preview totallandscapecare_com (preview_totallandscapecare_com)

Caption: Terex HR32 Crawler Excavator in jobsite field operations

Terex logoMidi Excavator

Terex HR32

Midi Excavator (6 - 10t) · Crawler Chassis

Operating Weight7.5 T Class
7,500 kg
≈ 16,534.6 lbs
Max Dig DepthGround Reach
2.80 m
≈ 9.2 ft
Net Engine PowerCrawler
72 HP
≈ 54 kW
Verified Technical Fact Sheet · Terex HR32

The official operating weight of the Terex HR32 is 7,500 kg (16,534.6 lbs), with a net engine output of 72 HP and a maximum digging depth of 2.80 m. Classified as a Midi Excavator (6 - 10t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
KHD BF 4 M
Net Power
72 HP (54 kW)
Gross Power
72 HP
Displacement
3.2 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
7,500 kg
Weight (lbs)
16,534.6 lbs
Hydraulic System Flow
155.2 L/min
Fuel Tank Capacity
N/A
Standard Bucket
0.08 m³

Working Dimensions & Dig Depth

Max Digging Depth
2.80 m (9.2 ft)
Max Reach (Ground)
7.47 m
Max Dump Height
4.30 m
Shipping Width
2316 mm
Shipping Height
2713 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Terex Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Terex HR32 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Terex HR32

How much does a Terex HR32 excavator weigh?

The official operating weight of the Terex HR32 hydraulic excavator is 7,500 kg (16,534.6 lbs) (7.5 metric tonnes), categorizing it within the Midi Excavator (6 - 10t) range.

What is the maximum digging depth of the Terex HR32?

The maximum digging depth for the Terex HR32 is 2.80 m (9.2 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Terex HR32 have?

The Terex HR32 is powered by a KHD BF 4 M powertrain delivering 72 HP (54 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Terex HR32?

The Terex HR32 is classified as a Midi Excavator (6 - 10t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
