Terex TXC300LC2 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Terex TXC300LC2 Crawler Excavator in jobsite field operations

Terex logoHydraulic Excavator

Terex TXC300LC2

Large Excavator (25 - 50t) · Crawler Chassis

Operating Weight30.7 T Class
30,653 kg
≈ 67,578.2 lbs
Max Dig DepthGround Reach
11.63 m
≈ 38.2 ft
Net Engine PowerCrawler
197 HP
≈ 147 kW
Verified Technical Fact Sheet · Terex TXC300LC2

The official operating weight of the Terex TXC300LC2 is 30,653 kg (67,578.2 lbs), with a net engine output of 197 HP and a maximum digging depth of 11.63 m. Classified as a Large Excavator (25 - 50t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
DL08
Net Power
197 HP (147 kW)
Gross Power
197 HP
Displacement
7.64 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
30,653 kg
Weight (lbs)
67,578.2 lbs
Hydraulic System Flow
494.4 L/min
Fuel Tank Capacity
N/A
Standard Bucket
1.3 m³

Working Dimensions & Dig Depth

Max Digging Depth
11.63 m (38.2 ft)
Max Reach (Ground)
17.41 m
Max Dump Height
11.93 m
Shipping Width
3405 mm
Shipping Height
3456 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Terex Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Terex TXC300LC2 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Terex TXC300LC2

How much does a Terex TXC300LC2 excavator weigh?

The official operating weight of the Terex TXC300LC2 hydraulic excavator is 30,653 kg (67,578.2 lbs) (30.7 metric tonnes), categorizing it within the Large Excavator (25 - 50t) range.

What is the maximum digging depth of the Terex TXC300LC2?

The maximum digging depth for the Terex TXC300LC2 is 11.63 m (38.2 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Terex TXC300LC2 have?

The Terex TXC300LC2 is powered by a DL08 powertrain delivering 197 HP (147 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Terex TXC300LC2?

The Terex TXC300LC2 is classified as a Large Excavator (25 - 50t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
