Terex TXC420LC1 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Terex TXC420LC1 Crawler Excavator in jobsite field operations

Terex logoHydraulic Excavator

Terex TXC420LC1

Large Excavator (25 - 50t) · Crawler Chassis

Operating Weight41.2 T Class
41,200 kg
≈ 90,830.3 lbs
Max Dig DepthGround Reach
5.07 m
≈ 16.6 ft
Net Engine PowerCrawler
281 HP
≈ 210 kW
Verified Technical Fact Sheet · Terex TXC420LC1

The official operating weight of the Terex TXC420LC1 is 41,200 kg (90,830.3 lbs), with a net engine output of 281 HP and a maximum digging depth of 5.07 m. Classified as a Large Excavator (25 - 50t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
DE12TIS
Net Power
281 HP (210 kW)
Gross Power
281 HP
Displacement
11.06 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
41,200 kg
Weight (lbs)
90,830.3 lbs
Hydraulic System Flow
630.3 L/min
Fuel Tank Capacity
N/A
Standard Bucket
1.91 m³

Working Dimensions & Dig Depth

Max Digging Depth
5.07 m (16.6 ft)
Max Reach (Ground)
12.07 m
Max Dump Height
8.33 m
Shipping Width
3353 mm
Shipping Height
3575 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Terex Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Terex TXC420LC1 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Terex TXC420LC1

How much does a Terex TXC420LC1 excavator weigh?

The official operating weight of the Terex TXC420LC1 hydraulic excavator is 41,200 kg (90,830.3 lbs) (41.2 metric tonnes), categorizing it within the Large Excavator (25 - 50t) range.

What is the maximum digging depth of the Terex TXC420LC1?

The maximum digging depth for the Terex TXC420LC1 is 5.07 m (16.6 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Terex TXC420LC1 have?

The Terex TXC420LC1 is powered by a DE12TIS powertrain delivering 281 HP (210 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Terex TXC420LC1?

The Terex TXC420LC1 is classified as a Large Excavator (25 - 50t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
