Liebherr A311 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Liebherr A311 Crawler Excavator in jobsite field operations

Liebherr logoMobile Excavator

Liebherr A311

Source-Verified

Medium Excavator (10 - 25t) · Crawler Chassis

Operating Weight12.5 T Class
12,500 kg
≈ 27,557.7 lbs
Max Dig DepthGround Reach
4.10 m
≈ 13.5 ft
Net Engine PowerCrawler
94 HP
≈ 70 kW
Verified Technical Fact Sheet · Liebherr A311

The official operating weight of the Liebherr A311 is 12,500 kg (27,557.7 lbs), with a net engine output of 94 HP and a maximum digging depth of 4.10 m. Classified as a Medium Excavator (10 - 25t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
BF4M2012
Net Power
94 HP (70 kW)
Gross Power
95 HP
Displacement
4 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
12,500 kg
Weight (lbs)
27,557.7 lbs
Hydraulic System Flow
180 L/min
Fuel Tank Capacity
N/A
Standard Bucket
0.31 m³

Working Dimensions & Dig Depth

Max Digging Depth
4.10 m (13.5 ft)
Max Reach (Ground)
8.40 m
Max Dump Height
6.75 m
Shipping Width
N/A
Shipping Height
N/A
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Liebherr

Liebherr A311 Official Specification Sheet

Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Region: EU
Engine Rating Standards
Net: ISO 9249
Gross: ISO 14396
Market: EU
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Liebherr A311 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Liebherr A311

How much does a Liebherr A311 excavator weigh?

The official operating weight of the Liebherr A311 hydraulic excavator is 12,500 kg (27,557.7 lbs) (12.5 metric tonnes), categorizing it within the Medium Excavator (10 - 25t) range.

What is the maximum digging depth of the Liebherr A311?

The maximum digging depth for the Liebherr A311 is 4.10 m (13.5 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Liebherr A311 have?

The Liebherr A311 is powered by a BF4M2012 powertrain delivering 94 HP (70 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Liebherr A311?

The Liebherr A311 is classified as a Medium Excavator (10 - 25t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
