Mustang ME3003 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Industrial Field Photography

Caption: Mustang ME3003 Crawler Excavator (Authentic series representative)

Mustang logoMini Excavator

Mustang ME3003

Mini Excavator (2 - 6t) · Crawler Chassis

Operating Weight3.1 T Class
3,118 kg
≈ 6,874 lbs
Max Dig DepthGround Reach
2.23 m
≈ 7.3 ft
Net Engine PowerCrawler
29 HP
≈ 22 kW
Verified Technical Fact Sheet · Mustang ME3003

The official operating weight of the Mustang ME3003 is 3,118 kg (6,874 lbs), with a net engine output of 29 HP and a maximum digging depth of 2.23 m. Classified as a Mini Excavator (2 - 6t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
3TNV88-NNS
Net Power
29 HP (22 kW)
Gross Power
36 HP
Displacement
1.64 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
3,118 kg
Weight (lbs)
6,874 lbs
Hydraulic System Flow
98.8 L/min
Fuel Tank Capacity
N/A
Standard Bucket
0.15 m³

Working Dimensions & Dig Depth

Max Digging Depth
2.23 m (7.3 ft)
Max Reach (Ground)
4.97 m
Max Dump Height
3.32 m
Shipping Width
N/A
Shipping Height
2408 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Mustang Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Mustang ME3003 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Mustang ME3003

How much does a Mustang ME3003 excavator weigh?

The official operating weight of the Mustang ME3003 hydraulic excavator is 3,118 kg (6,874 lbs) (3.1 metric tonnes), categorizing it within the Mini Excavator (2 - 6t) range.

What is the maximum digging depth of the Mustang ME3003?

The maximum digging depth for the Mustang ME3003 is 2.23 m (7.3 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Mustang ME3003 have?

The Mustang ME3003 is powered by a 3TNV88-NNS powertrain delivering 29 HP (22 kW) net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Mustang ME3003?

The Mustang ME3003 is classified as a Mini Excavator (2 - 6t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
