Yanmar VIO203 Hydraulic Excavator Jobsite Operation
VLM Certified Authentic Imagery
Watch Video
Photo: Machinery Media Network

Caption: Yanmar VIO203 Crawler Excavator in jobsite field operations

Yanmar logoMini Excavator

Yanmar VIO203

Mini Excavator (2 - 6t) · Crawler Chassis

Operating Weight2.2 T Class
2,230 kg
≈ 4,916.3 lbs
Max Dig DepthGround Reach
1.90 m
≈ 6.2 ft
Net Engine PowerCrawler
N/A
≈ N/A
Verified Technical Fact Sheet · Yanmar VIO203

The official operating weight of the Yanmar VIO203 is 2,230 kg (4,916.3 lbs), with a net engine output of N/A and a maximum digging depth of 1.90 m. Classified as a Mini Excavator (2 - 6t) (Crawler chassis).

Engine & Powertrain

Engine Make / Model
3TNV76PBV
Net Power
N/A
Gross Power
19.2 HP
Displacement
1 L
Emissions Standard
EPA Tier 4 / EU Stage V

Operational & Hydraulics

Operating Weight
2,230 kg
Weight (lbs)
4,916.3 lbs
Hydraulic System Flow
76.1 L/min
Fuel Tank Capacity
N/A
Standard Bucket
0.08 m³

Working Dimensions & Dig Depth

Max Digging Depth
1.90 m (6.2 ft)
Max Reach (Ground)
4.16 m
Max Dump Height
2.45 m
Shipping Width
1381 mm
Shipping Height
2402 mm
Specification Provenance

Source & Configuration

How we verify specifications→
Official Literature
Yanmar Technical Specification
Benchmark Operating Configuration

Standard OEM factory configuration: crawler undercarriage with standard mono boom, standard arm, and general purpose excavation bucket.

Engine Rating Standards
Market: Global OEM
Verified:2026-10-02

Authentic In-Field Operation Footage

Real-world Yanmar VIO203 jobsite telemetry & machine handling demonstration

Technical FAQ & Field Knowledge

Frequently Asked Questions about Yanmar VIO203

How much does a Yanmar VIO203 excavator weigh?

The official operating weight of the Yanmar VIO203 hydraulic excavator is 2,230 kg (4,916.3 lbs) (2.2 metric tonnes), categorizing it within the Mini Excavator (2 - 6t) range.

What is the maximum digging depth of the Yanmar VIO203?

The maximum digging depth for the Yanmar VIO203 is 1.90 m (6.2 ft), offering optimal ground reach for civil utility trenching, footings, and earthmoving.

What engine and horsepower does the Yanmar VIO203 have?

The Yanmar VIO203 is powered by a 3TNV76PBV powertrain delivering N/A net engine power, engineered for high fuel efficiency and hydraulic breakout force.

What class of excavator is the Yanmar VIO203?

The Yanmar VIO203 is classified as a Mini Excavator (2 - 6t) Crawler excavator, engineered for civil earthmoving, commercial construction, utility trenching, and severe-duty site excavation.
